Ebro

23 x 152,4 cm

EASY INSTALLATION
SOUND INSULATION
COMFORT, SUITABLE FOR UNDERFLOOR HEATING
HIGH PRESSURE
IMPACT RESISTANCE
HYGIENIC AND STAIN RESISTANT
UV RESISTANCE
100% RECYCLABLE
WATER RESISTANCE

Pieces

23×152,4 cm

23EBR025411

Detail

Detail

Environments

Packing

[tablefield field-name=»packing» table-class=»my-table»]

See Packing

Technical characteristics

ISO 23999
DIMENSIONAL STABILITY

ISO 23999
DIMENSIONAL STABILITY

EN 13501-1
FIRE RESISTANCE

ISO 10874
USE CLASSIFICATION

ISO 24343-1
RESIDUAL INDENTATION RESISTANCE

EN ISO 26987
CHEMICAL RESISTANCE

NORMA DIN 51130
SLIP RESISTANCE
<= 0,15% <= 1 mm Clase B (Bfl – s1) 33 <= 1% (mm) RESISTS R-9

Installation manual

01

FIRST PLANK, FIRST ROW

Begin with the plank to be installed in the corner. Remove the locking system on the long side that is going against the wall by cutting it. Place a spacer on the left with predicted thickness for the perimeter joint and position the panel against the wall.

02

SECOND PLANK, FIRST ROW

Press the short end of the next plank at an angle to the first one, and then fold down. Complete the first row in the same way.

03

At the end of the first row, put a spacer with the width of the perimeter joint next to the wall and measure the length from the edge of the last installed plank to the spacer, so you can cut the last plank to fit.

04

SECOND ROW

First panel min length 1/3 of the plank’s length place a spacer against the left hand side wall.

05

Staggered joint distance i.e. minimum distance between short ends of panels in parallel rows should be no less than the given length.

06

Place the plank and angle against the plank in the previous row, press forward and fold down at the same time.
Leave the plank in a somewhat up angled position when the planks start to lock.

07

SECOND PLANK, SECOND ROW

Place the short end of the plank at an angle against the previous installed plank and fold down all the way.

08

Once inserted the short side on the locking system, fold the short side of the plank to be installed with an angle between 20-30º, so it can be inserted in the long side of the previous row. This will incline all the planks already installed in the current row.

09

AFTER 2-3 ROWS

Adjust the distance to the front wall by placing spacers.
Keep the spacers in position during the entire time of installation and remove once the installation is completed.

10

LAST ROW (AND PERHAPS ALSO FIRST ROW)

The minimum width on the last row must be 50 mm.
Place a spacer to the wall before measuring. Measure and mark the plank along the wall. Cut the panels lengthwise including the locking system.

Drill holes twice the size of the diametre of the pipes. Cut and remove a piece of the panel with a vinyl cutter, so the panel with the drilled holes can be placed next to the pipe. Put the panel on one side of the pipes and the removed piece on the other side.

Remove the vertical locking part of the strip with a vinyl cutter, put applicable glue on the strip and push the panels horizontally together. Place some spacers between the last board and the wall.

Separate the whole row by carefully lifting and release the locking system in the whole row. Fold up the row and release the whole long side. Disassemble the panels by angling the short sides up vertically.

Installation tips

INSTALLATION AROUND RADIATOR/HEATING PIPES

Drill holes twice the diameter of the pipes. Cut out a piece from the panel with a utility knife. Place the panel on one side of the pipes, and the cut-out part on the other side.

WHEN ANGLING IS NOT POSSIBLE

Remove the locking element with a chisel, put glue on the area and push the panels together horizontally. Place a few spacers between the last board and the wall.

DISMANTLING PANELS

Separate the entire row by carefully lifting and release the entire row. Fold the row and release the entire long side. Disassemble the panels by lifting the short sides upwards.

IMPORTANT INFORMATION

The packages must be allowed to acclimatise for a minimum of 24 to 48 hours prior to installation, in the room where the flooring is to be installed.

In rooms larger than 10x10 (100m2), the floor should be installed in smaller sections with expansion joints.

Leave a gap of about 5 mm to walls and other permanent building elements (such as pillars and kitchen islands).

Never install very heavy furniture, such as kitchen islands/cabinets, on top of the floor.

The indoor temperature should be between 18º and 30º and the relative humidity of the air between 30 and 60% (according to the Swedish Institute for Standards)

Always follow the floor manufacturer's requirements and specifications regarding the preparation of the subfloor.

Serie EBRO 23 x 152,4 cm
